Fire-Rated Architectural 1/8-inch and 1-inch Pan Floor Door
The Nystrom fire-rated architectural pan door is the industry's leading solution for seamless sight lines, long-lasting quality and fire rated safety.
Features
- 2- or 3-hour fire-ratings tested to NFPA 288
(1/8" has 2- or 3-hour rating, 1" has 2-hour only) - 1/8-Inch or 1-Inch pan sizes to receive a variety of flooring materials
- 1/8" pan in sizes up to 52" x 96"
- Lock options for added security
- Improved interior release handles
- Installs in wood or concrete applications
Specifications
| Model | FDF L/P -T1/-P1 |
| Sizes 1/8" Pan | 250 psf 24" – 48" width x 24" – 60" length 150 psf >48" – 52" width x >60" – 96" length |
| Sizes 1" Pan | 250 psf 24" – 48" width x 24" – 48" length |
| Door | Single |
| Cover Material | Aluminum: 1/4 inch smooth plate with 1/8-inch or 1-inch pan, Mill finish |
| Frame Material | Aluminum |
| Fire-Rating | 1/8” has 2- or 3-hour fire rating, 1” has 2-hour rating |
| Frame | Extruded Aluminum Angle |
| Installation | Cast-In Standard or Bolt-In Optional |
| Spring | Enclosed coil, Type 17-7 Stainless Steel |
| Hinge | Heavy-duty Type 316 Stainless Steel |
| Latch | Slam latch zinc-plated steel with inside lever handle |
| Compliance | NFPA 288, Warnock Hersey label tested and listed by Intertek |
| Options | Self-closing mechanism, recess padlock hasp, mortise prep |
| Warranty | 5 years |
Order Guide
Use the table below to guide specification of available options. The part number components are indicated in BOLD ORANGE text.
Fire Rated Architectural 1/8-Inch Pan Floor Door
FDF is standard with 2-hour rating unless 3-hour rating is chosen under "Options"
| MODEL | LOAD | MATERIAL | WIDTH | X | LENGTH | COVER & INSTALL | OPTIONS |
|---|---|---|---|---|---|---|---|
FDF |
P - 250 psf L - 150 psf |
A - Aluminum | 24" – 48" (250 psf)1 >48" – 52" (150 psf)2 |
24" – 60" (250 psf) 60" – 96" (150 psf) |
SWLS - Single DoorW - Anchors Provided L - Handle |
T1 - 1/8-inch tile door 3HR - 3 Hour rating3 BI - Bolt-in Installation4 SC - Self closing mechanism |
1The load will default to "P" (250 psf) for doors up to and including 48" x 60" (e.g. FDFPA36x36SWL)
2The load will default to "L" (150 psf) for doors greater than 48" x 60" (e.g. FDFLA50x75SWL)
3up to 48" x 60" only and 250 psf only
42-hour only
Fire Rated Architectural 1-Inch Pan Floor Door
| MODEL | LOAD | MATERIAL | WIDTH | X | LENGTH | COVER & INSTALL | OPTIONS |
|---|---|---|---|---|---|---|---|
FDF |
P - 250 psf | A - Aluminum | 24" – 48" | 24" – 48" |
SWLS - Single DoorW - Anchors Provided L - Handle |
P1 - 1-inch Pan Door BI - Bolt-in Installation SC - Self closing mechanism |
WARRANTY
NYSTROM warrants all Floor Doors to be free from manufacturing defects in materials, factory finishes, and workmanship for a period of five (5) years from the date of shipment.
Should a product fail to function in normal use within this period, Nystrom shall furnish a replacement or new part at Nystrom's discretion. Failure to use product in methods consistent with Nystrom product manuals shall relieve Nystrom of any liability. Our liability under this warranty excludes installation or removal costs involved in the product replacement and excludes any responsibility for incidental or consequential damage of any nature.
For information on a warranty claim, please visit our Warranty Support section or call 800-547-2635.
Videos
Coming soon.| Description | Model | Size | Shop Drawing | CAD | BIM | Data Sheet | 3-Part Specs | LEED | Installation | Warranty |
|---|---|---|---|---|---|---|---|---|---|---|
| 1/8" Pan Door | ||||||||||
| 2-Hour Cast-in | FDF | < 48x60 | DWG | LINK | WORD | |||||
| 2-Hour Bolt-in | FDF | < 48x60 | DWG | LINK | WORD | |||||
| 2-Hour Cast-in | FDF | > 48x60 | DWG | LINK | WORD | |||||
| 2-Hour Bolt-in | FDF | > 48x60 | DWG | LINK | WORD | |||||
| 3-Hour Cast-in | FDF | < 48x60 | DWG | LINK | WORD | |||||
| 1" Pan Door | ||||||||||
| 2-Hour Cast-in | FDF | < 48x48 | DWG | LINK | WORD | |||||
| 2-Hour Bolt-in | FDF | < 48x48 | DWG | LINK | WORD | |||||
Product Change Notice - 04/16/2021
