Seismic Pre-Compressed Heavy Duty Foam System Recessed Application (EJN-PDX)
The Nystrom Seismic Pre-Compressed Heavy Duty Foam System is a primary seal creating a watertight joint system for high traffic areas. The patented composite rod system allows this seal to hold up against high movement and heavy pedestrian and cart loads.
Features
- Traffic-Durable
- Watertight
- Parking Deck Application
- Non-Invasive Anchoring
- Wax-Free
Specifications
| Model | PDX |
| Material | Foam with Silicone Bellow |
| Sizes | 1 inch to 4 inches Additional sizes available in 1/2 inch increments from 1 to 4 inches |
| Length | 6.56 linear feet |
| Application | Interior or Exterior |
| Installation | Floor or Deck |
| Options | Terminations, Transitions, Additional Sizes, Seal Depths and Dual Sided available upon request |
| Movement | +/- 50% (Total 100%) |
| Warranty | 1 year |
| Colors |  Concrete Gray (Standard) |
 Traffic Grade Black |
 Highway Gray |
Order Guide
Use the table below to guide specification of available options. The part number components are indicated in BOLD ORANGE text.
| PART NUMBER | JOINT SIZE at mean T° F |
SEAL DEPTH |
|---|---|---|
| EJN-PDX-100 | 1" (25mm) | 2" (51mm) |
| EJN-PDX-150 | 1.5" (38mm) | 2" (51mm) |
| EJN-PDX-200 | 2" (51mm) | 3" (76mm) |
| EJN-PDX-250 | 2.5" (64mm) | 3" (76mm) |
| EJN-PDX-300 | 3" (76mm) | 3" (76mm) |
| EJN-PDX-350 | 3.5" (89mm) | 3" (76mm) |
| EJN-PDX-400 | 4" (102mm) | 4" (102mm) |
Movement of +/-50% (Total 100%)
Additional sizes available in 1/4" increments from 1" to 4".
WARRANTY
NYSTROM warrants all Expansion Joint Systems to be free from manufacturing defects in materials, factory finishes, and workmanship for a period of one (1) year from the date of shipment.
Should a product fail to function in normal use within this period, Nystrom shall furnish a replacement or new part at Nystrom's discretion. Failure to use product in methods consistent with Nystrom product manuals shall relieve Nystrom of any liability. Our liability under this warranty excludes installation or removal costs involved in the product replacement and excludes any responsibility for incidental or consequential damage of any nature.
For information on a warranty claim, please visit our Warranty Support section or call 800 547-2635.
Videos
Coming soon.| Description | Model | Shop Drawing | CAD | Revit/BIM | Data Sheet | 3-Part Specs | LEED | Installation | Warranty |
|---|---|---|---|---|---|---|---|---|---|
| Parking Deck | EJN-PDX-100 | DWG | |||||||
| Parking Deck | EJN-PDX-150 | DWG | |||||||
| Parking Deck | EJN-PDX-200 | DWG | |||||||
| Parking Deck | EJN-PDX-250 | DWG | |||||||
| Parking Deck | EJN-PDX-300 | DWG | |||||||
| Parking Deck | EJN-PDX-350 | DWG | |||||||
| Parking Deck | EJN-PDX-400 | DWG |
